Product Description:
Retroreflector Meter is a portable instrument that provides
multiple measurements with a simple calibration procedure. It
features a measuring aperture area of 340mm X 95mm, a continuous
working time of battery of more than 72h, an angle of incidence of
88.76° and a complementary angle of 1.24°. It also comes in a
beautiful red color. This multipurpose device is ideal for various
applications, and is suitable for both indoor and outdoor use. With
its user-friendly design, it is easy to use and highly reliable.
Features:
- Product Name: Retroreflector Meter
- Light source color temperature: 2856±50K
- Charger: DC 8.4V
- Error of repeatability measurement: ≤3% (Small measurement error)
- Complementary angle: 1.24°
- Instrument size: 700mm X 135mm X 115mm
- Free preheating time: 20 minutes (Free preheating time)
- High accuracy: ±1.5% (High accuracy)
Technical Parameters:
| Parameter | Value |
|---|
| Charger | DC 8.4V |
| Collor | Red |
| Angle of incidence | 88.76° |
| Error of repeatability measurement | ≤3% |
| Measurement range | 0---4000 |
| Complementary angle | 1.24° |
| Data storage space | 8GB |
| Ambient humidity | ＜98%, No Frost |
| Built-in battery capacity | 13Ah |
| Observation angle | 1.05° |
| Multiple measurements | Yes |
| Rapid measurement | Yes |
| Portable instrument | Yes |
Applications:
The STP-MR retroreflector meter, produced by STP, is a
high-performance product certified by CCC. It features high
stability structure, simple calibration procedure, high accuracy,
high resolution, compact design, and easy to use. With a minimum
order quantity of 1 piece and a price range of 3000- 3500 Yuan, it
is packaged in an inner box and master carton, with 1pc per carton.
Its delivery time is 7 days, and the payment terms are T/T. It has
a maximum supply ability of 1000 and a continuous working time of
battery of over 72 hours. It has 8GB of data storage space, a
complementary angle of 1.24°, and a built-in battery capacity of
13Ah. The ambient humidity should be below 98%, and it should not
be exposed to frost. The STP-MR retroreflector meter is designed to
provide reliable and accurate measurements in a variety of
applications.
Customization:
Retroreflector Meter
Brand Name: STP
Model Number: STP-MR
Place of Origin: CHINA
Certification: CCC
Minimum Order Quantity: 1
Price: 3000-3500
Packaging Details: inner box and master carton , 1pc per carton
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 1000
Ambient temperature: -15℃~+60℃
Data storage space: 8GB
Built-in battery capacity: 13Ah
Measuring aperture area: 340mm X 95mm
Complementary angle: 1.24°
This Retroreflector Meter is featured for its high precision, rapid
measurement, and multiple measurements.
Packing and Shipping:
Retroreflector Meter Packaging and Shipping:
The Retroreflector Meter is packaged in a sealed box and shipped
with a cushioning material to ensure safe storage and
transportation. All of the parts are securely packed and labelled
to ensure safe delivery and to prevent any potential damage. The
box is printed with the product name, description, and instructions
for use. Once the package is placed in the shipping container, it
is sealed to protect against any dirt, dust, or environmental
elements. The package is then shipped to the customer’s specified
address.
